boiwsa is an R package for performing weekly seasonal
adjustment on time series data. It provides a simple, easy-to-use
interface for calculating seasonally adjusted estimates of weekly data,
as well as a number of diagnostic tools for evaluating the quality of
the adjustments.
The seasonal adjustment procedure is based on a locally-weighted least squares procedure (Cleveland et al., 2014).
We consider the following decomposition model:
\[ y_{t}=T_{t}+S_{t}+H_{t}+O_{t}+I_{t}, \]
where \(T_{t}\), \(S_{t}\) , \(O_{t},\) \(H_{t}\) and \(I_{t}\) represent the trend, seasonal, outlier, holiday- and trading-day, and irregular components, respectively. The seasonal component is modeled as
\[ \begin{eqnarray*} S_{t} &=&\sum_{k=1}^{K}\left( \alpha _{k}^{y}\sin (\frac{2\pi kD_{t}^{y}}{ n_{t}^{y}})+\beta _{k}^{y}\cos (\frac{2\pi kD_{t}^{y}}{n_{t}^{y}})\right) + \\ &&\sum_{l=1}^{L}\left( \alpha _{l}^{m}\sin (\frac{2\pi lD_{t}^{m}}{n_{t}^{m}} )+\beta _{l}^{m}\cos (\frac{2\pi lD_{t}^{m}}{n_{t}^{m}})\right) , \end{eqnarray*} \]
where \(D_{t}^{y}\) and \(D_{t}^{m}\) are the day of the year and the day of the month, and \(n_{t}^{y}\) and \(n_{t}^{m}\) are the number of days in the given year or month. Thus, the seasonal adjustment procedure takes into account the existence of two cycles, namely intrayearly and intramonthly.
The trend component is extracted with Friedman’s SuperSmoother using
stats::supsmu().
Like the X-11 method (Ladiray and Quenneville, 2001), the
boiwsa procedure uses an iterative principle to estimate
the various components. The seasonal adjustment algorithm comprises
eight steps, which are documented below:
Step 1: Estimation of trend (\(T_{t}^{(1)}\)) using
stats::supsmu().
Step 2: Estimation of the Seasonal-Irregular component:
\[y_{t}-T_{t}^{(1)}=S_{t}+H_{t}+O_{t}+I_{t}\]
Step 2*: Searching for additive outliers
Step 2**: Identifying the optimal number of trigonometric variables
Step 3: Computing seasonal factors (and possibly other factors as \(H_{t}\) or \(O_{t}\)) using WLS. In this version, for each year \(t\) and the observation year \(\tau\) we use a simple geometrically decaying weight function \(w_{t}=r^{|t-\tau|}\), where \(r \in (0,1]\).
Step 4: Estimation of trend (\(T_{t}^{(2)}\)) from seasonally and outlier
adjusted series using stats::supsmu()
Step 5: Estimation of the Seasonal-Irregular component: \[y_{t}-T_{t}^{(2)}=S_{t}+H_{t}+O_{t}+I_{t}\]
Step 6: Computing the final seasonal factors (and possibly other factors as $ H_{t}$ or \(O_{t}\)) using WLS.
Step 7: Estimation of the final seasonally adjusted series: \[y_{t}-S_{t}-H_{t}\]
Step 8: Computing final trend (\(T_{t}^{(3)}\)) estimate from seasonally and
outlier adjusted series using stats::supsmu().
To install boiwsa, you can use devtools:
# install.packages("devtools")
devtools::install_github("timginker/boiwsa")Alternatively, you can clone the repository and install the package from source:
git clone https://github.com/timginker/boiwsa.git
cd boiwsa
R CMD INSTALL .Using boiwsa is simple. First, load the
boiwsa package:
library(boiwsa)Next, load your time series data into a data frame object. Here is an
example that is based on the gasoline data from the
fpp2 package:
data("gasoline.data")
plot(gasoline.data$date,gasoline.data$y,type="l",xlab="Year",ylab=" ", main="Weekly US gasoline production")
Once you have your data loaded, you can use the boiwsa
function to perform weekly seasonal adjustment:
res=boiwsa(x=gasoline.data$y,dates=gasoline.data$date)The x argument takes the series to be seasonally
adjusted, while the dates argument takes the associated dates in date
format. Unless specified otherwise (i.e., my.k_l = NULL),
the procedure automatically identifies the best number of trigonometric
variables to capture the yearly (\(K\))
and monthly (\(L\)) cycles based on the
AICc. The information criterion is specified by the ic
option. The weighting decay rate is specified by r (by
default r=0.8).
The procedure automatically searches for additive outliers (AO) using
the method described in Appendix C of Findley et al. (1998). To disable
the automatic AO search, set auto.ao.search = F. To add
user-defined AOs, use the ao.list option.
The boiwsa function returns a list object containing the
results. The seasonally adjusted series is stored in a vector called
sa. In addition, the estimated seasonal factors are stored
as sf.
You can then plot the adjusted data to visualize the seasonal pattern:
plot(gasoline.data$date,gasoline.data$y,type="l",xlab="Year",ylab=" ", main="Weekly US gasoline production")
lines(gasoline.data$date,res$sa,col="red")
legend(
"topleft",
legend = c("Original", "SA"),
lwd = c(2,2),
col = c("black", "red"),
bty = "n"
)
To evaluate the quality of the adjustment, you can use the
plot_spec function provided by the package, which generates
a plot of the autoregressive spectrum of the raw and seasonally adjusted
data:
plot_spec(res)
Cleveland, W.P., Evans, T.D. and S. Scott (2014). Weekly Seasonal Adjustment-A Locally-weighted Regression Approach (No. 473). Bureau of Labor Statistics.
Findley, D.F., Monsell, B.C., Bell, W.R., Otto, M.C. and B.C Chen (1998). New capabilities and methods of the X-12-ARIMA seasonal-adjustment program. Journal of Business & Economic Statistics, 16(2), pp.127-152.
Ladiray, D. and B. Quenneville (2001). Seasonal adjustment with the X-11 method.
The views expressed here are solely of the author and do not necessarily represent the views of the Bank of Israel.
Please note that boiwsa is still under development and
may contain bugs or other issues that have not yet been resolved. While
we have made every effort to ensure that the package is functional and
reliable, we cannot guarantee its performance in all situations.
We strongly advise that you regularly check for updates and install any new versions that become available, as these may contain important bug fixes and other improvements. By using this package, you acknowledge and accept that it is provided on an “as is” basis, and that we make no warranties or representations regarding its suitability for your specific needs or purposes.
